High Performance Fiber Optic Gyro Low Bias Angular Speed Sensor

Name: High Performance Fiber Optic Gyro Low Bias Angular Speed Sensor
Brand: Firepower
Price: 800 USD

Best High Performance Fiber Optic Gyro Low Bias Angular Speed Sensor wholesale

Model Number : MFOG-24A

MOQ : 1

Payment Terms : L/C,T/T

Brand Name : Firepower

Price : 800

Supply Ability : 200/MONTH

Delivery Time : 1 week

Packaging Details : Sponge+ box

Sensor name : low bias gyro

Bias stability : ≤2°/h

Bias repeatability : ≤2°/h

Angular random walk : ≤0.04°/h

Dimension : φ24X39mm

Weight : ≤30g

Contact Now

The MFOG-24 represents a new generation of miniaturized fiber optic gyroscopes, integrating optical path assembly, control electronics, and robust housing. Its simple structure, fast response, and low noise make it an ideal choice for platform stabilization, inertial navigation, and precision attitude measurement applications.

4 Weight

≤30g.

4.5 Operating temperature

-40℃~+65℃.

4.6 Storage temperature

-55℃~+85℃.

4.7 Random vibration

Random vibration level: 20g, frequency range: 20Hz ~ 2000Hz.

4.8 Main performance parameters

Table 1 Main Performance Parameters

Serial number	Project	Performance indicators
Serial number	Project	MFOG-24	MFOG-24-AN
1	Range (°/s)	±500	±300
2	Scale factor	3600(LSB/o/s)	7mv/o/s
3	Scale factor nonlinearity (ppm)	300	≤1000
4	Zero-bias stability (10s, 1σ, °/h)	≤1.5	≤2
5	Zero-bias repeatability (1σ, °/h)	≤1.5	≤2
6	Angular random walk (°/h ^1/2)	≤0.03	≤0.04
7	Zero bias (°/s)	≤0.02	≤0.05
8	3dB Band Width (Hz)	≥300	≥450
9	Power supply (V)	5+0.15	5+0.15
10	Power Consumption (W)	≤1.5	≤0.7
11	Dimension (mm)	φ24X39

External Power Supply Requirements

	+5V
Voltage	4.85V~5.15V
Ripple	20mV
Electric current	0.2A
